Types of Thermometer
6 Minutes · Chitti Videos
Types of thermometers explained for students, covering clinical, laboratory, and digital thermometers. A Tamil physics lesson.
- How clinical thermometers use mercury and a kink to read fever
- How laboratory thermometers measure liquids without a kink
- How digital thermometers use heat sensors to display readings
What this lesson teachesRead the lesson as text
A thermometer is an instrument used to measure temperature, such as human body warmth or the heat of liquids in a laboratory. The two traditional types are clinical thermometers and laboratory thermometers, alongside modern digital thermometers.
Clinical thermometer
A clinical thermometer is designed for measuring human body temperature in homes and hospitals, covering a range from 35 degrees Celsius to 42 degrees Celsius. It contains mercury inside an airtight bulb connected to a tube marked with Celsius and Fahrenheit scales. Between the bulb and the tube, a narrow bend called a kink prevents the mercury from dropping when exposed to surrounding air after leaving the mouth. After reading the temperature, the thermometer is shaken so the mercury returns to the bulb, and it is cleaned in an antiseptic solution to kill microbes before the next use.
Laboratory thermometer
- It is used in school laboratories and industries to measure higher temperatures, such as the boiling point of water.
- It contains mercury or alcohol sealed in a tube marked with Celsius units.
- It does not have a kink, so the liquid level drops as soon as it is removed from the substance.
- It must be kept upright and read while the bulb is directly touching the substance, without tilting.
Digital thermometer
A digital thermometer uses a heat sensor instead of a glass bulb to detect heat and display the reading on a screen. It can be used for both clinical body measurements and laboratory testing across a wide range of temperatures. Even though digital models are widely used today, hospitals still keep mercury clinical thermometers as backups in case the electronic batteries fail.
Safety and handling
- Never touch the bulb of a clinical thermometer with your fingers, as your own body heat alters the measurement.
- Handle glass thermometers with care because mercury is extremely poisonous if the glass cracks.
- Avoid tilting a laboratory thermometer during use, as tilting leads to an incorrect reading.
- Always sanitize clinical thermometers in antiseptic liquid between patients so illnesses do not spread.
