Plane Angles

4 Minutes · Chitti Videos

Plane angles explained for students, covering degrees, radians, and how to measure angles using a pizza slice. A Tamil physics lesson.

  • Why rockets need correct angles to launch safely
  • How radians and degrees are used as units of plane angles
  • Measuring radians with a pizza slice, pi, and full circle angles
What this lesson teachesRead the lesson as text

A plane angle is a measure of how much two connected lines spread apart or close together at the point where they join. It is a fundamental concept in science and mathematics used to determine direction and tilt.

Why angles are important

When a small festival rocket is launched straight up, tilting even slightly will make it fly sideways into a neighbouring house. If large space rockets or military missiles tilt by a tiny amount during launch, the resulting damage can be disastrous. Science and mathematics use the concept of an angle to measure this tilt precisely so paths can be controlled.

Units of plane angles

  • Just as mass is measured in kilograms and length in metres, angles also have standard units of measurement.
  • The degree was the first unit discovered and used for measuring angles.
  • Scientists later introduced the radian to make large and complex calculations much simpler.
  • The radian was officially adopted as the SI unit for plane angles.

Measuring radians with a pizza

A circular pizza provides a simple way to show how a radian is measured. The distance from the center of the pizza to the outer rim is the radius, and the curved outer edge of any slice is called an arc. When the length of this curved arc is made equal to the radius, lines drawn from the ends of the arc to the center create an angle. Dividing the arc length by the radius gives an angle measurement of exactly one radian.

From radians to a full circle

When the lines spread farther apart, the arc length grows and the angle increases through one, two, and three radians. At half a circle, the angle reaches 3.14 radians, which is three plus 0.14 and is called pi. Completing the full circle gives two pi radians, which is equal to 360 degrees. Dividing 360 degrees by two pi shows that one radian is equal to 57.3 degrees.
