Scales of Thermometer

6 Minutes · Chitti Videos

Thermometer scales for students: learn how Fahrenheit, Celsius, and Kelvin units were created. A Tamil physics lesson.

  • Daniel Gabriel Fahrenheit setting ice, body, and boiling points
  • Andreas Celsius dividing ice and boiling water into 100 steps
  • Lord Kelvin establishing absolute zero and the Kelvin scale
What this lesson teachesRead the lesson as text

Thermometer scales are standardized numerical systems used to measure temperature, with the three primary units being Fahrenheit, Celsius, and Kelvin. Each scale relies on distinct physical reference marks, such as the temperature of freezing ice and boiling water, to define its numerical intervals.

The Fahrenheit scale

Daniel Gabriel Fahrenheit developed this scale in the eighteenth century, when it became widely used because it provided reasonably accurate readings for that era. He placed an unmarked mercury thermometer into ice, then against his body, and finally into boiling water, marking each mercury level on the glass. He assigned 32 degrees Fahrenheit to ice, 96 degrees Fahrenheit to human body temperature, and 212 degrees Fahrenheit to boiling water. He chose to start at 32 instead of zero so that these values would remain whole numbers, though testing other people later revealed that normal body temperature is actually 98.6 degrees Fahrenheit.

The Celsius scale

  • Andreas Celsius designed this scale using an unmarked thermometer placed first into ice and then into boiling water.
  • He assigned the ice level a value of zero and the boiling water level a value of 100.
  • He divided the interval between the freezing and boiling points into 100 equal steps.
  • The system is also known as centigrade because the word centi means 100 and grade means steps.
  • It is widely used today for air conditioners, microwave ovens, and weather forecasts because a zero-to-one-hundred range is simple to use.

The Kelvin scale

Lord Kelvin designed this scale to help scientists who faced difficulties working with negative numbers caused by sub-zero temperatures in places like the Arctic and Antarctic. He investigated how cold materials could become and discovered a limit beyond which no object could be cooled. He established this lowest boundary as absolute zero or zero Kelvin, below which no substance can cool, creating the absolute scale. On this scale, water freezes at 273 Kelvin and boils at 373 Kelvin, and unlike Celsius and Fahrenheit, the word degree is never used.
