The Mathematics Behind Speedometers
4 Minutes
How speedometers use maths for students, showing how wheel size and pi affect calculated vehicle speed. A short maths lesson in Tamil.
- How pi relates a wheel's diameter to circumference (சுற்றளவு)
- How a drive shaft magnet and sensor measure rotation time
- Why changing to larger wheels causes speedometer errors
What this lesson teachesRead the lesson as text
A speedometer calculates vehicle speed using mathematics by measuring the time a wheel takes to rotate and multiplying that by the wheel's circumference. The circumference is the distance around the outer edge of the wheel, which equals the diameter multiplied by the mathematical constant pi.
Pi and wheel circumference
- The diameter is the straight measurement across the center of a circular wheel.
- When a wheel rolls through one complete turn, it travels a distance equal to 3.14 times its diameter.
- This ratio is known as pi, and it remains constant for circles of any size.
- This total outer boundary distance covered in one complete roll is the circumference (சுற்றளவு).
Measuring rotation with sensors
A magnet is fixed onto the vehicle drive shaft, which rotates along with the wheels. A stationary magnetic sensor is placed next to the drive shaft and wired to an electronic circuit. Each time the magnet spins past the sensor, an electric current pulse is transmitted to the circuit. The circuit notes the time of the first pulse as T1 and the second pulse as T2, and subtracting T1 from T2 gives the time taken for one full rotation.
Calculating vehicle speed
The electronic circuit already has the circumference of the car wheel stored inside its memory. Speed is determined using the mathematical formula where speed equals distance divided by time. The circuit divides the stored circumference distance by the measured rotation time, and it immediately displays the calculated speed on the speedometer.
Errors from changing wheel size
- Replacing small wheels with larger wheels means the car travels a longer distance with each single rotation.
- If the speedometer circuit is not retuned, it continues calculating speed using the old, smaller circumference value.
- This causes the speedometer to display a speed that is lower than the actual speed of the vehicle on the road.
- A driver might appear to follow the speed limit on the dashboard while actually moving fast enough to be caught by a police speed gun.
