Linkage

1 Minute

Linkages for kids: learn how linked rods transfer force in scissor lifts, cycle brakes, and bike engines. A Tamil science lesson.

  • How linkages and joints transfer motion in scissor lifts
  • How links and brake pads stop a bicycle wheel
  • How piston and crank linkages drive a motorbike wheel
What this lesson teachesRead the lesson as text

A linkage is a mechanism made of two or more interconnected rods that transfers force and motion. It allows a machine to receive movement in one direction and output motion in a completely different direction.

Basic parts of a linkage

  • The individual rods in the mechanism are called links.
  • The connecting points where the rods meet are called joints.
  • Connecting rods through joints allows force and motion to travel from one part to another.
  • This structure gives machines the ability to redirect movement to where it is needed.

Scissor linkages in lifts

A scissor linkage uses connected rods to redirect motion. When the two ends of this mechanism are pressed together, the linkage moves in a direction perpendicular to the applied force. This perpendicular movement is what allows scissor lifts to raise platforms upward.

Linkages in bicycle brakes

  • A bicycle brake uses two links connected at a joint.
  • The upper ends of the links connect to the brake wire.
  • The lower ends of the links attach to two brake pads.
  • Pulling the hand brake pulls the brake wire upward, which forces the lower brake pads inward to arrest the spinning wheel.

Linkages in motorbike engines

Inside a motorbike engine, a piston and a crank are joined together by links. When petrol burns in the engine, it forces the piston to move up and down. This linkage transfers the up-and-down movement to the crank, causing the crank to rotate. As the crank spins, it rotates the motorbike wheel and drives the vehicle forward.
